Shenzhen SMT PCB Assembly for LED Lighting & Dispenser PCB PCBA Boards In China

Specifications

Our Services

STHL 14+ Years One-Stop PCB & PCBA Factory

High-quality PCB PCBA Factory PCB Assembly Manufacture



Company Information

 Shenhen STHL Electronics Co., Ltd. is a professional electronic manufacturing services (EMS) manufacturer in Shenzhen,China,with 4000 square meters factory areas,about 150 employees, 10-15 R&D staffs.

 We offers one -stop PCB assembly service for prototypes and low-volume to MID-volume orders.

 as an IS09001 certificated electronics assembly manufacturer,we work all projects exactly complain with ROHS standard and quality guarantee.

Our Teams



STHL management team are 10+ years experience in PCB and PCBA field, our sales representatives are very stable and mostly worked here since the company establish. They can help you remember your projects details and requested. and our engineers can contact with customers directly in English if necessary, the faster and more effective communication helps lead time a lot.



Our Professinal Team

STHL management team are 10+ years experience in PCB and PCBA field, our sales representatives are very stable and mostly worked here since the company establish. They can help you remember your projects details and requested. and our engineers can contact with customers directly in English if necessary, the faster and more effective communication helps lead time a lot.



PCBA Capability

Items	PCBA capacity
Product name	Mobile app controlled elevator drone flight controller board PCB
Assembly details	SMT and Thru-hole, ISO SMT and DIP lines
Testing on products	Testing jig/mold , X-ray Inspection, AOI Test, Functional test
Quantity	Min quantity : 1pcs. Prototype, small order, mass order, all OK
Files needed	PCB : Gerber files(CAM, PCB, PCBDOC)
	Components : Bill of Materials(BOM list)
	Assembly : Pick-N-Place file
PCB Panel Size	Min size : 0.25*0.25 inches(6*6mm)
	Max size : 1200*600mm
Components details	Passive Down to 0201 size
	BGA and VFBGA
	Leadless Chip Carriers/CSP
	Double-sided SMT Assembly
	Fine BGA Pitch to 0.2mm(8mil)
	BGA Repair and Reball
	Part Removal and Replacement
Component package	Cut Tape, Tube, Reels, Loose Parts
PCB+ assembly process	Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching----- Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT---- -FunctionTesting-----Temperature & Humidity

PCBA Capabilities

PSMT PCB Assembly Capabilities

We are equipped with advanced assembly and inspection equipment to support reliable PCB Assemblies. Our highly trained and experienced staff make sure your projects completed faster with high quality. Our capabilities in high-quality SMT PCB assembly services include, but not limited to:

 Ball Grid Array (BGA)
 Ultra-Fine Ball Grid Array (uBGA)
 Quad Flat Pack No-Lead (QFN)
 Quad Flat Package (QFP)
 Small Outline Integrated Circuit (SOIC)
 Plastic Leaded Chip Carrier (PLCC)
 Package-on-Package (PoP)
 Small Chip Packages (pitch of 0.2 mm)
 AOI inspection
 X-Ray Inspection

PCB Assembly Capabilities

 Armed with advanced equipment and supported by a sophisticated technical team, STHL Technology provides extremely reliable turnkey PCBA manufacturing services cover the following: PCB layout & design, material sourcing, IC programming, SMT assembly, THT assembly, mixed technical assembly, ICT test, function testing, conformal coating, cable assembly and labeling, as well as complete box build service.



STHL excellent PCBA

STHL PCBA offers excellent PCBA services include:

1. Automated and manual fine pitch SMT

2. BGA with X-RAY and rework capability

3. Lead-free assembly

4. Wave soldering

5. in circuit testing

6. Function testing

7. Conformal coating

8. Burn in

9. AOI inspection systerm

10. X-RAY inspection



FAQ

1.What is your MOQ?

Our MOQ is 1 PCS, sample and mass production all can support.



2.how could I can a quotation?

PCB: Please send us Gerber file.

PCBA:Please send us Gerber file+BOM



3.Are you factory?

Yes,we are a true factory.



4.Can you produce the goods as customer design?
Welcome to send us the design or sample, we will calculated the cost and unit price for you as soon as possible.



5.how about the products packing?
Flexible packing according to the specific requirements of the clients.



6.Are my design files secure when I send them to you?

We can sign NDA,don't worry your files are held in complete safety and security.



7. how can you make sure the components quality?

We buy components from famous international platform like Mouser, Digikey, Farnell, Future, Avnet, Arrow or agents. Repeat orders material normally ordered from the same source, we do not change suppliers time by time if everything goes well.and  we have IQC workers test.



8. how long is the delivery time?

Make PCB board or pcba assembly  need 15-20 workdays ,Test the function need 1-2workdays.
