LDP Type 5 Ton Single Girder Bridge Crane with CD Electric Hoist Trolley

FOB Price:	5697.00 - 9963.00 USD/Set
Supply Ability:	50,000 Set(s) per Year
Shipping:	Ocean shipping
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Henan in China
Packaging Details:	Export standard wooden box packing

Quick Details

Feature: Bridge Crane
After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 1 year
Certification: CE ISO EAC
Condition: New
Feature: High efficient
Model Number: LDP
Brand Name: Kuangyuan
Span: 7m-31.5m
Max. Lifting Height: 30m
Max. Lifting Load: 5 Ton
Rated Lifting Moment: 50 KN
Rated Loading Capacity: 5 Ton
Application: workshop
Name: Single girder overhead crane
Lifting mechanism: hoist trolley
Lifting speed: 8m/min
Traveling speed: 20m/min
Protection class: IP54
Color: Customized
Electrical parts: Schneider
Warranty: 1 year
Working duty: A3
Standard: DIN/FEM/GB

Specifications

LDP Type 5 Ton Single Girder Bridge Crane with CD Electric Hoist Trolley

LDP model EOT Single Girder Ovehead Crane is designed as light type lifting equipment according to China standard. It is equipped with the features of reasonable structure,max.Lifting height, strong rigidity of whole set. this crane equips with wire rope electric hoist to lift different cargoes, its capacity can vary 1--20ton and span 7.5---31.5m, working class A3-A4 according to ISO standard.this kind of crane is widely used in factory, warehouse, stuff yard to lift goods, forbidden to use in flammable, explosive and corrosive environment (we have explosion proof and casting single girder crane for special condition). this single girder overhead crane is operated by pendent control or remote control.
LDP Type 5 Ton Single Girder Bridge Crane With CD Electric Hoist Trolley

Feature: 1.Enough lifting height 2.Lifting speed: Single/double lifting speed 3.Trolley travelling speed: 20m/min 4.Working class: M3~M4 5.Control way: pendant control+ remote control 6, Full safety system as follows: Weight overload protection Emergency stop system Over current protection Short-circuit protection Phase sequence protection Zero position protection Voltage loss protection Overhigh lift and overlow lift limit switch
LDP Type 5 Ton Single Girder Bridge Crane with CD Electric Hoist Trolley
