2.4X18m Dryer Produced by Jiangsu Pengfei Group

FOB Price:	1.00 - 99999.00 USD/Set
Supply Ability:	150 Set(s) per Year
Shipping:	shippment to shanghai port
Payment Terms:	L/C, D/A, D/P, T/T

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	Southeast Asia, Africa, Mid East, Eastern Asia
Place of Origin:	Jiangsu in China
Packaging Details:	chinese standard container

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 2 years
Certification: ISO9001
Brand Name: Pengfei
Condition: New
Weight: according to different sizes
Dimension(L*W*H): according to different sizes
Power(W): according to different sizes
Voltage: according to different sizes
Model Number: according to different sizes
Production Capacity: according to different sizes

Specifications

Movement Way:	Fixed
Heating Mode:	Air
Drying Medium:	Air
Operation Pressure:	Atmospheric Dryer
Structure:	Rotary Type Drier
Operational Method:	Continuous

Customization:

Available

Basic Info.

Model NO.

2.4x18

Appearance of Dried Sample

Particle

Type of Flow

Parallel Flow

Type of Atomization

Not Applicable

Sprayer

Not Applicable

Product Description

Φ2.418m Dryer
Rotary speed of shell: 0.88-8.8 r/min
Slope: 2-3.5%
Capacity: 10-60 t/h (Determined according to initial moisture and final moisture)
Speed adjustable motor: YCT315-4A-37kw
Reducer: ZSY224-II
Module of bull gear & pinion: Z1/Z2=24/160
Steel plate for shell: Q235-B,
Thickness of common plate: 16mm
Thickness of plate under tyre: 40mm
Total weight of equipment: 54t
