the Hydrophobic & Lipophilic Filter by Graphene Filter with Good Oil Abosrbing Effect

FOB Price:	1.00 - 10000.00 USD/Sheet
Supply Ability:	10,000 Set(s) per Month
Shipping:	customizable
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Tianjin in China
Packaging Details:	customizable

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Certification: customizable
Weight: customizable
Brand Name: MSTN/Mstnland/OEC
Condition: New
Dimension(L*W*H): customizable
Model Number: Isplitter

Specifications

theHydrophobic andLIpophilicFIlter

Working principle:
Graphene is combined with the adsorption material through a special process, so that the adsorption material has the characteristics of lipophilic and hydrophobic. At the same time, the complete regeneration of adsorption materials is achieved through simple extrusion/back blowing to achieve the purpose of reuse and reduce solid waste.

Product Advantages:

1. It has good removal effect on floating oil, emulsified oil and partially dissolved oil in water;

2. the core lipophilic and hydrophobic adsorption material can be reused and has a long service life;

3. There is no need to add extra chemicals, and the rate of water content of regenerated oil is low, which can be used for oil recovery;

4. the adsorption rate is high, and the adsorption of crude oil can reach more than 120 times of its own weight (the traditional adsorption material can only reach about 20 times);

5. the desorption rate of oil phase is high, which can reach more than 95%;

6. the regeneration of adsorption material is simple, which can be completed only by extrusion or back blowing. and the regeneration energy consumption is low;

Project case:
the comparison of inlet and outlet water of oily sewage treatment project in tank farm of a refining and chemical enterprise
the Hydrophobic Lipophilic Filter by Graphene Filter with Good Oil Abosrbing Effect

Specification:

Length: Non-standard, customizable
Diameter: Non-standard, customizable
Processing capacity: 1-10m3/h
Processing customization: Yes
Working pressure: ≤0.2mPa
Oil intake: less than or equal to 5000mg /L
Oil content: less than or equal to 50mg/L
Liquid suspended matter: ≤600mg/L
Liquid suspension: ≤50mg/L
Treatment object: oil-water separation of all kinds of wastewater containing oil, oil slick and emulsified oil. the water content of the separated oil is low, no other impurities are introduced, and the oil can be recovered
Operation mode: series, parallel can be adjusted according to the actual situation
Operating temperature: 10-90℃
Purpose: oil and water separation, oil recovery
Model:Isplitter
