Home >Products Catalog > Smart Switch > SmartLife Tuya App Remote Control Mini Smart Relay WiFi Switch Module Works with Alexa & Google Home

SmartLife Tuya App Remote Control Mini Smart Relay WiFi Switch Module Works with Alexa & Google Home

Supply Ability:	200,000 Piece(s) per Month
Shipping:	7 days for samples, 25 days for bulk orders
Payment Terms:	T/T, Western Union, MoneyGram, Safebuy, Other, Paypal

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China

Quick Details

Max. Voltage: 240V
Max. Current: 10A
Operating Temperature: 25
Brand Name: Netplus
Power Supply: 100-240V
Model Number: SH-WiFi-SW01-10A
Protocol: Wi-Fi 2.4GHz

Specifications

SmartLife Tuya App Remote Control Mini Smart Relay WiFi Switch Module Works with Alexa and Google Home
Netplus 1-channel WiFi switch module is a perfect solution for transfering your home electrical appliances to the IoT(Internet of Thing) devices. It can be installed behind exising regular switches, in a distribution box or in a ceiling fitting. Then you will enable to turn on/off the lights, electrical appliances or cut off power by your cellphone App from anywhere.

Features:

Wi-Fi connected - Use your existing home Wi-Fi network to achieve wireless control, No HUB required;
Mobile App Control - Turn a wide range of appliances ON-off directly from mobile App, no matter where you are;
Quick Pairing - Pair the smart module with your phone quickly and easily via Bluetooth connection;
Highly Compatibility - this smart switch module is compatible with existing normal switches;
Voice Control - Support voice control via amazon Alexa/Echo/Dot, Google Home, Yandex, etc;
Time Schedule - Create custom schedules based on your agenda or follow the sunrise or sunset;
Smart Scenarios - Create smart scenarios by linking smart relays with other Netplus smart devices.

Technical Data

Basic Information
Product Type	Smart on-off Switch
Article	1-channel Wi-Fi Relay Switch Module 10A
Art. No.	SH-WiFi-SW01-10A
Input	AC100-240V 50/60Hz
Output	AC100-240V 50/60Hz
Load	Max. 10A
Channels	1 channel
Power Measurement	No
Management App	SmartLife or TuySmart App
Operation Range	< 200 meters
Standby Power	< 0.5W
Overload Protection	Yes
Neutral Wire Required	Yes
Warranty	2 years
Certificates	CE / EMC / LVD
Connectivity
Protocol	Wi-Fi 2.4GHz & Bluetooth
Wireless Standard	IEEE 802.11 b/g/n
Antenna	A ceramic antenna integrated on PCB board
Security Module	WPA / WPA2
Encryption Type	WEP / TKIP / AES
Operating Systems	Android & iOS
Appearance
Dimension	40 mm x 40 mm
Depth	18 mm
Colour	White
Net Weight	35 g
Casing Material	PC V0
Working Environment
Operation Temp.	-10C - +40C
Case Temp.	Tc: +80C (Max.)
Working Humidity	5% - 95% RH, non-condensing
IP Rating	IP20 for indoor use
