High Speed Roller Shutter Door for Cold Storage

In Stock

Inquiry Now

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Beijing in China
Packaging Details:	Wooden Package

Quick Details

APPLICABLE PLACE:

Food industry, cold chain logistics, agriculture and animal husbandry, medicine/medical appliance in the constant temperature and humidity places

FEATURES:

Automatic and fast door cycle improves logistics efficiency
Tight seal and insulated curtain reduce air flow, energy transmission to save energy, and protect against bad weather and dust-free
Flexible curtain without rigid elements avoids injuries and damages, which is safe for personnel and/or equipment
Self-reinserting door curtain avoids down-time

TECHNICAL PARAMETERS:

Application	Interior doors
Maximum size (W*H)	4,000 mm x 6,000 mm
Opening speed	1.5 m/s-2.8 m/s
Closing speed	0.5 m/s-1.2 m/s
Opening and closing frequency	>60 cycles/hour
Frame structure	Galvanized zinc-coated steel (option: stainless steel)
Reel material	Stainless steel
Side guide strip	Reinforced polyethylene with antifreeze/heat wire
Motor	Power: 1.5 KW, IP rating: IP65
Control system	Control box-switch button, emergency stop, power switch, Operating information feedback, IP rating: IP 65
Safety device	100% soft bottom edge, photoelectric protection on the door rail, wireless safety soft bottom edge protection system (option: safety grating)
Voltage Frequency	Single-phase/220V-13A frequency:50-60Hz
Air / Water permeability	Class I according to EN12426 / EN12425
Wind load	Class I according to EN12424
Curtain colors	RAL 5002 RAL 1003 RAL 7046 RAL 2004
Recommended operating temperature	-30C up to+5C
