Features:
1) Type: 2-bore, 4-stroke, liquid-cooled
2) Bore x stroke: 76 x 71mm
3) Displacement: 646cc(250cc/800cc/1100cc/1800cc available)
4) Compression ratio: 8.4:1
5) Carburetor: BJH101E or CSH101E
6) Max. Power: 20.6kW/5,300rpm
7) Max. Torque: 44/2,700 - 3,300N.m/rpm
8) Starting: electric
9) Ignition: C.D.I
10) Lubrication: force and splash
11) Transmission: manual clutch, 4 shift / reverse
12) Spark plug: -F6T or F6TC
13) Plug gap: 0.7 ?0.1mm
14) Fuel type: RQ93 (unleaded)
15) Lubricate oil: SAE-15W/30
16) Fuel tank: 28.0L
17) Engine oil: 2,900ml
18) Coolant: 4,000ml
19) Starting: <5s
20) Climbing: 30?
21) Battery: 12V, 36Ah
22) Head light: 12V, 150W/both
23) Tail light: 12V, 82W/both
24) Fuse: 30A
25) Brake rack: < 7m at 20miles/h
26) Top speed: 58 miles/h (or limited as customers require)
27) Front, rear brake: hydraulic disc, right foot control
28) Front tire: 25 x 8 - 10
29) Rear tire: 25 x 10 - 12
30) Front suspension: independent dual A-arm
31) Rear suspension: independent longitudinal control arm
32) Final drive: shaft driven
Outer packing:
N.W: 300kg
G.W: 330kg
Conveyance:
Qty/20' FCL: 8pcs
Qty/40' HQ: 24pcs
| Place of Origin: | ZHEJIANG wenzhou in China |
| Model No: | XY-KD021(epa approved,4wd,1100/1800cc) |
