Wireless Camera (ES-KC23R4)

Detailed Product Description

Wireless Camera Kit Model: ES-KC23R4
Features ●CMOS 380 TV line, OV chipset, high definition ●Waterproof camera, IR distance 5-10 meters, with audio ●Four cameras , with automatic switching function
Receiver 703 Specification
Receiving Frequency	CH1: 2414MHz CH2: 2432MHz CH3: 2450MHz CH4: 2468MHz
Video Output	75Ω/1Vp-p
Audio Output	10KΩ/200mVp-p
Signal Output	One audio and one video;
Power Consumption	＜2W
Working Temperature	0_~40℃
Power Adapter	DC12V/500mA

Camera C23 Specification
TV System	PAL	NTSC
Validity Pixel	628(H) x 586(V)	510(H) x 496(V)
Image Device	1/3" Omn Vision CMOS
Transmission Frequency	CH 1: 2414MHz； CH 2: 2432MHz； CH 3: 2450MHz； CH 4: 2468MHz.
Horizontal Definition	380TV line
Minimum Illumination	0LUX
Transmission Signal	Audio and Video
Transmission Distance in Open Field	30～50m
Power Consumption	< 1W
Working Temperature	-10℃~50℃
Syncronization System	Internal
Scanning Frequency(H)	15. 625KHz		15. 734KHz
Scanning Frequency(V)	50Hz		60Hz
Backlight Compensation	Auto
Electronic Shutter	1/50(1/60)~1/100, 000sec
White Balance	Auto
S/N Ratio	> 48db
Power Adapter	DC5V /500mA

Place of Origin:	Shenzhen in China
Model No:	ES-KC23R4(R703+C23*4)
Brand Name:	ES
Payment Terms:	T/T(Bank Transfer),Western Union,
