DXDD-F350C Powder four side sealing packing machine
Characteristics：
Two-step roller four-side sealing, continuous running not only fast in speed, stable in running, low in noise, but also firm in sealing, reliable in airtight, with bags coming smoothly and fine, high in packing efficiency.
An imported frequency changer is adopted for step-less speed adjusting, intelligent temperature control regulates the temperature at the sealing. It has reliable performance, convenient operation.
Photoelectric tracking system is adopted to ensure the automatic correcting of the double face printing design on the packing bags, precise in counting.
Liquid & crystal touching display screen is adopted to realize the menus type speaks between man and machine.
It can do step-less adjustment for pouch length and width, suitable for packing middle dosage.
Material feeding setting adopts high accuracy stepper motor to drive, PLC to control and screw to fill. It can stop filling completely, accurate in measuring, more suitable for high speed packing machine.
It is applicable to a wide using, suitable for all of the complex film packing materials.
Usage：
It is suitable to pack powder materials in the fields of pharmacy industry, food industry and chemical industry. Such as flour, coffee powder, lotus root starch, bean-milk powder, bone-strong powder, spirulina powder etc.
Main technology parameter： cold water circle(self-provided)
Pouch length 60-250mm(adjustable)
Pouch width 60-175mm （adjustable）
Max packing speed 50strokes/min
Filling capacity 3-250ml
Applicable film PET/AL/PE PET/PE NY/AL/PE NY/PE
Max packing width 350mm
Max film diameter Φ300 mm
Film core diameter Φ70-76 mm
Electric source 220V 50Hz
Total power 4.5 Kw
G.W. 650 Kg
Package size 1400?000?700(L譝譎)
| Place of Origin: | zhejiang Ruian in China |
| Model No: | DXDD-F350C |
| Brand Name: | zhongbao |
| Minimum Order: | 1 set |
| Package: | wood case |
| Delivery Time: | 35-45 |
