Specifications:
1>Dimensions (L*W*H )(mm): 1, 650*750*1. 070
2>Wheel base (mm):1,175
3>Min.ground clearance (mm):250
4>Dry weight (kg):78
5>Max. Loading weight(kg)150
6>Max. Speed(km/h): >95
7>Brake method(F/R): Disk/disk
8>Tire size(F/R): 2. 5-14/3. 0-12
9>Seat height(mm): 825
10>Suspension(Front): telescopic fork, upside-down
11>Suspension(Rear):central mono rear shock
12>Fuel capacity: 4L
Engine specifications:
1>Engine type: 150cc, 1-cylinder, air-cooled, 4-stroke
2>Bore x stroke (mm):62 x 49.50
3>Piston swept volume(ml):149.4ml
4>Compressing ratio:9.2:1
5>Max. Power and speed: 8. 2KW/8600
6>Max. Torque(N. M/rpm): 8. 8kw/7,500-8,000
7>Clutch type: Moist
8>Starting method: Kick/electric
9>Lubrication way: press and splash
10>Ignition: CDI
11>Transmission: 4-speed, manual clutch
12>Drive train:chain, 15T/48T
Outer packing: Carton with steel frame
Carton dimensions: 1, 465*435*765mm
Conveyance: 58pcs/20' 120pcs/40'
COLOUR: Blue, red, black, yellow, green, orange, pink, white
CE, ISO9001: 2000, VIN
| Place of Origin: | Zhejiang Yongkang in China |
| Model No: | MTLDB-002AL-150CC |
| Brand Name: | MTL |
| Minimum Order: | one 20'FCL |
| Supply Ability: | 10000pcs/month |
| Package: | carton with steel frame |
| Delivery Time: | T/T, |
