Oblique arm structure, motor drive the printing arm lift;
Transducer is introduced to control the printing process;
The movement of scraper, ink covering, blades and screen departure is controlled by pneumatic parts make speed and pressure no matter symmetrical but also step less modulating, it is prolong the life of screen and improved print quality;
Stainless steel platform with vacuum absorbing, equipped with register micro-adjust;
Table being adjusted from tri-direction by micro-adjuster, it make proofreading easy;
Equipped with safety guard
As a whole, this machine is simple operation, safety, low noise, running steadily and printing precise.
Main Technical parameters
Model :FB-4060D
Max.printing acreage :400x600mm
Print station acreage :600x700mm
Voltage :380V/50Hz
Printing speed :1300t/h
Dimensions of the machine :1380x780x1300
--------------------------------------------------------------
Model :FB-6080D
Max.printing acreage :600x800mm
Print station acreage :800x900mm
Voltage :380V/50Hz
Printing speed :1200t/h
Dimensions of the machine :1620x980x1300
---------------------------------------------------------------
Model :FB-6090D
Max.printing acreage :600x900mm
Print station acreage :800x1000mm
Voltage :380V/50Hz
Printing speed :1200t/h
Dimensions of the machine :1620x1080x1300mm
| Place of Origin: | Zhejiang Wenzhou in China |
| Model No: | FB-4060D/6080D/6090D |
| Brand Name: | Feibao |
| Supply Ability: | 20 |
| Package: | Wooden |
| Delivery Time: | 15 |
