Capacitor (CBB61)
Specifications:
1. Reference standard: GB 3667-1997 (IEC 252-1992)
2. Working temperature: -40 ℃ to +85℃
3. Rated voltage: 450 VAC, 500 VAC
4. Capacitance range: 0.5 uF ~ 20 uF
5. Capacitance tolerance: ±5% (J), ±10% (K)
6. Voltage proof:
Between terminals: 2 UR (5s)
Terminals to case: 2 UR +1000 VAC
7. Dissipation factor: ≤0. 001 (1KHz)
8. Insulation resistance: 5000 MΩ. UF
9. RoHS
