16 channel Real time DVR

Detailed Product Description

Detailed Product Description
High speed embedded CPU and real time embedded control operation system are adapted with the product, it provide operation stability, no hang-up error, more reliability and easy for maintain.
Operation with front panel and remote control, menu language also available for English / Chinese (simplified) / Chinese (traditional), security with double password
lock. System management require for authority code in order to provide safety
system.
Using with hardware ADPCM encode to provide better streaming quality, it also support
with D1, 1/2D1, CIF resolution, as well as adjustable frame rate and provide
space efficiency with compact video size
Storage used with FAT32 format, suitable for 8 IDE hard drive connections, there
are 3 types of store method can use in here: individual, compound and mixed.
Provide multi-channels operation, such as:
  16 channel video input capture
  2 channel video (monitor and reply)
  1channel VGA output
16 channel audio input
2 channel audio (monitor and reply) output
16 channel alarm input with programmable setting
With kinds of surveillance display screen (1/4/16 windows per screen) and each individual display screen with audio surveillance function
Time setting to activate recording system with auto switching, system re-activate
after power shut down. Alert system for any video signal loss or disturb
Available for manual, time setting, alert playing, this will make the unit more effectively
and hard space efficiency. Also for the motion detect function available
with setting for 16X12(192) detect region area, with adjustable sensitivity
detect level
Pre-setting record function and extend alert function, in order to ensure alert information
100% capture with user requirement
Available for x2 and x4 fast forward/ backward function and slow motion rate at x1/2,
x1/4 and x1/8 as well as pause and frame-by-frame function
PAL/ NTSC system available
Individual setting for each capture channel for brightness, contrast, color, motion
detect setting
Complete daily report for alarm record and operation record, good for monitor record
and analysis RJ-45 network inlet/ outlet available for the internet function for ADSL, ISDN, intrane
