Pocket bike

Detailed Product Description

1) Model no.: ATV-3150-D
2) Engine: 150cc air cooled fully-automatic
3) Max. speed: 60km/h
4) Ignition method: CDI
5) Start way: electric start
6) Transmission method: chain
7) Front tire: 23 x 7-10
8) Rear tire: 22 x 10-10
9) Wheelbase: 1,030mm
10) Ground clearance: 190mm
11) Brake: a) Front brake: drum brake
b) Rear brake: disc brake
12) Compression ratio: 9.5:1
13) Max. power: 6.0/8,000 (kW/r/min)
14) Max. torque: 7.8/6,500 (N.m/r/min)
15) Bore x stroke: 57.4 x 57.8
16) Max. load: 80kg
17) Full tank volume: 7.8L
18) Battery: 12V, 9Ah
19) Net weight: 170kg
20) Gross weight: 180kg
21) Model dimensions: 1,770 x 990 x 1,025mm
Packing:
Dimensions: 143x 83x 74cm
Conveyance:
Qty/40' HQ: 57pcs
