Specifications:
1) 6-needle, 20-head
2) Emb. area: 300 x 1,000mm
3) Table size: 7,300 x 2,500mm
4) Speed: 250 - 850rpm
5) Power input: 220V / 380V, 50Hz / 60Hz
6) Power consumption: 0.75kw
7) Noise: < 80dB
8) Configuration: DAHAO computer, clutch motor (made in Taiwan), three-
phase stepper motor, Servo motor ( made in Japan ), hook (made in
Japan), bobbin case (made in Japan), encoder (made in Japan)
9) We can customize the machine to meet our customer needs.
Functions:
1) Auto repeat of embroidery
2) Sticking cloth embroidery
3) Return and complementary embroidery
4) Auto bulk embroidering
5) High/low speed idle running
6) Thread broken detecting
7) Auto return to the stop/original point
8) Manual frame moving
9) Adjustable rotating speed
10) Power failure protection
11) Disk output/input function
12) Design copy, editing &storing
13) Display by digit, liquid crystal
14) Rotating, enlarging and returning for embroidery design
15) Auto lubrication function (choose by client)
16) Auto/manual color changing (choose by client)
17) Auto thread cutting (choose by client)
Features:
1) Machine stand is made of large beam with advantage of high tensile
& steady moving
2) Heads, stitch frame, rotary hook case are all made by CNC
3) The rotary hook, bobbin case are made in Japan and less thread broken
is avoided
4) Three-phase stepper motor is used to improving steadiness greatly &low
noise-made
5) Use High speed color-changed motor to save time for color changing
As per the standard laid down by the ISO.We are certified ISO member
with ISO9001.
| Place of Origin: | Jiangsu in China |
| Model No: | TL620 TL920 |
| Brand Name: | TONGLI |
| Embroidery Machine: | Flat embroidery machine |
| Payment Terms: | L/C,T/T(Bank Transfer), |
| Minimum Order: | Set/Sets 1 |
| Supply Ability: | Set/Sets|500|Month |
| Package: | Vaccum and wooden case |
| Delivery Time: | 25 |
