ATV (ZL-ATV110-1)

1) Engine type: 50cc/70cc/90cc/110cc automatic clutch, air-cooled, single cylinder, 4 strokes.

2) Displacement: 49. 46/106. 7ml

3) Max. Power(Kw/r/min): 2. 6/(8, 500 + - 5%), 5. 0/8500

4) Max. Torque(N. M/r/min): 3. 0/(7, 500 + - 5%), 6. 7/6000

5) Compression rate: 9. 4: 1/9. 7: 1

6) Drive system: chain

7) Clutch: automatic clutch

8) Brake: rear hydraulic disc brake

9) Tire: 14. 5X7. 0-6(F/R)

10) Max. Speed: > =60km/h

11) Battery: 12V x 5Ah

12) Seat height: 570mm

13) Wheel base: 820mm

14) Ground clearance: 80mm

15) Suspension: front and rear hydraulic suspension

16) Ignition type: CDI

17) Start system: electric start

18) Dimensions: 1, 250 x 710 x 860mm

19) Max. Load: 150Kgs

* Packing:

* Steel frame and carton

* Carton dimensions: 1, 150 X 670 X 560mm

* Container: 68pcs/20", 136pcs/40", 136pcs/40"HQ

* N. W: 72Kgs

* G. W: 88Kgs
