ENGINE:Water-cooled two-stroke single cylinder engine
DISPLACEMENT: 39,8 cc
POWER: 10,5 kW at 12.300 rpm
TORQUE:8,1 Nm at 12.000 rpm
CARBURETOR: PHVA 17,5 Dellē¢ rto
EXHAUST: KIT B1 MODEL 2002
IGNITION: Contact-less
STARTING: Pull start
CLUTCH: Centrifugal automatic
FRAME: High Tensile steel tubing (welded)
BRAKES: front:disc brake - disc diameter 162 mm ( 6,3" )
Rear:disc brake - disc diameter 119 mm ( 4,7" )
WHEELS:front:light alloy 2,1" x 6.5"
Rear:light alloy 2,3" x 6.5"
TIRES:front:90/65 - 6,5"
Rear:110/50 - 6.5" or 90/65 - 6.5"
FUEL: Petrol 92 or higher Octane + 2-stroke synthetic oil (50:1)
FUEL TANK CAPACITY: 1 liter (0,26 US gal.)
WEIGHT: 25 kg ( 55 lb.) ( including stand 25,6 kg - 56,3 lb. )
WEIGHT INCL. PACKING: 30 kg ( 66 lb.)
MAXIMUM LOAD: 110 kg (242 lb.)
DIMENSIONS: length:1100 mm ( 41" )
Width:560 mm ( 22" )
Height:550 mm (21,6" )
PACKING BOX DIMENSIONS: length:109 cm
Width:37.5cm
Height:61cm
20" container:105pcs
40"container:230pcs
40"HQ container:296pcs
| Place of Origin: | Zhejiang Jinhua in China |
| Model No: | T-PB-006D |
