Electric Wire

Detailed Product Description

1. PVC Electeric Wires(300/500V)
Construction: Copper conductor, PVC insulation.
Application: Mainly used for fixed installation of electric
equipment, building wirings, electric power and lighting devices for A. C. rated voltages up to and includiing 450/750V.
Technical Dates: Max. Operatin temperature 70"C, short circuit temperasture Cross section 300mm2 160"C, Cross section >300mm2, 140"C.
Code: HO5V-U, HO5V-K, HO7V-U, HO7V-R.
2. PVC Flat & Twisted Cable(380V)
Copper Conductor PVC-insulated & Sheathed
Constrction: Copper conductor with PVC insulated
Application: in dry rooms for connecting portables appliance where mechanical stress is low.
Technical: Rated voltage 380V, Test voltage 2 KV, Operating temperature 70?C
Code: NYFAZ Nominal cross-sectio nal Area(mm2): 2*0. 75
Code: NYFAF Nominal cross-sectio nal Area(mm2): 2*0. 75
3. PVC Electric Cable(300/500V)
Copper Conductor PVC-Insulated & Sheathed
The PVC-Insulated PVC-Sheathed Electric Cables are mainly used for fixed installation of electric instruments, building wirings and electric power and lighting devices for A. C. rated voltage up to and including 300/500V.
4. PVC Electric Flat Cable (300/500V)
Copper Conductor PVC-Insulated & Sheathed
These products are mainly used for fixed installation of electric equipment, building wirings, telecommunication appliances and electric power and lighting devices for A. C. rated
Voltages up to and including 300/500V.
5. PVC Flexible Circular Cable(300/500V)
PVC-Insulated & Sheathed
Construction: Copper Conductor, PVC insulation, PVC outer and inner sheath
Rated Voltage: 300/500V
Application: Mainly used for fixed installatioin of electric equipment, building wirings electric power and lighting devices for A. C. Rated Voltages up to and including 300/500V.
Technical Dates: Min. Bending radius 6*D, Max. operating temperature 70?C
Short circuit temperature 160?C.
6. PVC Flexible Electric Cable (300/500V) with Protective
Conductor Copper Conductor PVC-Insulated & Sheathed
PVC-Insulated PVC-Sheathed Electric Cable with Circuit Protective Conductor is mainly used for fixed installation of electric equipment, building wirings, telecommunication appliances and electric power and lighting devices for A. C. rated voltage up to and including 300/500V.
