Features:
1) Lathe bed is cast wholly and firmly and will not deform
2) Imported ball screw rod and round guide rail to ensure accuracy
3) Subdivision stepper motor with excellent performance, quick speed,
stable operation, and big cutting movement to ensure long and safe
operation
4) Frequency conversion water-cooling large power motor for low noise, even
speed, and long operational life
5) Humanistic design, the machine can be disassembled, so it is easily transported
6) Applicable to:
a) Large advertising signs
b) Acrylic brands
c) PVC cutting
d) Tablets
e) Calligraphy
f) 3 dimensional characters
g) Gardening decorations
h) Wall decorations
Specifications:
1) Working travel: 1,200 x 2,400 x 100mm
2) Maximum carving speed: 6,000mm/min
3) Main shaft: 1,5kW, 2.2kW, 3kW, 4.5kW (optional)
4) Speed of main shaft: 0-24,000rpm
5) Cutters of main shaft: 3.175mm, 6.00mm, 8.00mm, 12.70mm
6) Power source: AC220/50Hz
7) Drive: stepper
8) Weight: 560kg
| Place of Origin: | Shandong Jinan in China |
| Model No: | XJ-1224 |
| Brand Name: | XJ-1224 |
| Package: | Wooden Box |
| Delivery Time: | 7 |
