Dirt Bike (MTLDB-110 B)

Specifications:

1) Dimensions (L x W x H): 1,665 x 780 x 1,045

2) Wheel base: 1,175mm

3) Min. Ground clearance: 280mm

4) Dry weight: 65kg

5) Max. Loading weight: 150kg

6) Max. Speed: > 85km/h

7) Brake method (front/rear): disk/disk

8) Tire size (front/rear): 2.5-14/3.0-12

9) Seat height: 770mm

10) Suspension (front): telescopic fork, upside-down

11) Suspension (rear): central mono rear shock

12) Fuel capacity: 4L

Engine specifications:

1) Engine type: 110cc, 1-cylinder, air-cooled, 4-stroke

2) Bore x stroke: 54 x 54

3) Piston swept volume: 124ml

4) Compressing ratio: 9.0: 1

5) Max. Power and speed: 6. 8kW / 7,500-8,500rpm

6) Max. Torque: 8.3N. M / 7,500rpm

7) Clutch type: moist

8) Starting method: kick

9) Lubrication way: press and plash

10) Ignition: CDI

11) Transmission: 4-speed, manual clutch

12) Drive train: chain, 14T/48T

Outer packing: Carton with steel frame

Carton dimensions: 1, 470 x 420 x 700mm
Conveyance:
Qty/20' FCL: 63pcs

Qty/40' HQ: 144pcs
