Supply two types: Grid-tie and grid-off type. And A set 1kw wind turbine contains:
Gnerator +Blade +Tail+Hub+ Controller + Inverter (grid-off) + Tower + Cable +Accessories.
Product got CE,ISO, CCC Certificates
Detail specification as followes:
Numbers of blade(P): 3
Materials of blade: FRP strengthened
Diameter of wind turbines(m)： 7.0
Startup wind speed ： 2
Rated wind speed(m/s) ： 10
Working wind speed (m/s): 3-25
Max. wind speed(m/s)： 45
Rated speed(rotate/minute)： 220
Start torque (n/m)： 7.5
Wind energy ratio(%)0.42
Generator rated power(W): 10000
Max.output power(W): 15000
Output voltage(V): 240VDC/360VDC/500VDC
Generator: Permanent-magnetic ,3-phase,AC
Speed regulation : Electromagnetic brake + Yawing
Stop method: Electromagnetic brake + Manual
Temperature Range: -40 ~ +60 Deg.C
Tower type: Free stand tower
Tower height (m): 12 & 18
Weight exclude tower(kg): 890
Annual generatoion Min/Max(kwh): 10000 / 30000
Inverter power supply: Pure Sine Wave( On-grid &Off-grid )
Controller Model : 240V100A / 360V100A / 500v100A
Battery: 12v150AH X40pcs (Off-grid type )
| Place of Origin: | China| |
| Model No: | 10000w |
| Brand Name: | SRM |
| Package: | Plywood case |
| Delivery Time: | 10-20days |
