* Packing:1pc/iron cage,with carton
* Size of carton:138x82x85cm
* N.W.:132KGS
* G.W.:145KGS
* 30pcs/1x20ft,66pcs/1x40HQ
1) Size of engine: 149.5cc/4 stroke/single cylinder/air cooled
2) Transmission system: chain drive
3) Bore x stroke (mm): 46.3 x 57.8
4) Compression Ratio: 9.2:1
5) Maximum Power (kw/r/min): 5.25/7500
6) Maximum Torque (N.m./rpm): 6.5/5750
7) Starter System: Electric Starter
8) Lubrication: Auto
9) Transmission: 4 speed, semi automatic
10) Overall dimensions (LxWxH): 1610 x 900 x 1030mm
11) Wheelbase: 900mm
12) Rim type: spoke / alloy
13) Min. Turning Radius (mm): 2000
14) Ground Clearance (mm): 100
15) Rider Capacity: 1 Person
16) Net Weight (kg): 150
17) Brake: front drum, rear disc
18) Tyre size: front - 19?-8; rear - 18?.5-8
19) Ignition Type: C.D.I.
20) Fuel Tank Capacity: 7.8L
21) Engine Oil Capacity: 0.9L
22) Gear Oil Capacity: 0.12L
23) Suspension: front - independent; rear - monoshock swing arm
24) Load Capacity: 100kg
25) Max. Speed: 60KM/H
26) Battery: 12V-9Ah
| Place of Origin: | China| |
| Model No: | AT10 |
