Lightning Arrester
Detailed Product Description
Type: HY5WS-51/134
1) The arrester's rated voltage (virtual value): 51KV
2) The constant operation voltage (virtual value): 40.8KV
3) The DC reference voltage (Ulm A) no less than: 73KV
4) The biggest remain voltage (climax value):
a) Under steep-wave surge current:
b) Under thunder lighting surge current:: 134KV
c) Under operation surge current:105KV
5) 2000us square wave current (climax value): 400A
6) 4/10us surge current (climax value): 65KA
7) The biggest leakage current under 0.75DC reference voltage: 50uA
|
