Engine type: WD615.67A / WD615.50
Power of engine: 206kw/2200r/min
Max. torque of engine: 1160Nm/ 1100-1600r/min
Boom base length: 10.76m
Max. rated lifting capacity: 25t
Working radius: 3-8m
Max. lifting height:10.51m
Fully extended boom: 32.3m
Max. lifting capacity: 6.5t
Working radius: 7-28m
Max. lifting height: 31.94m
Jib length: 8m
Max. lifting capacity: 2.5t
Max. lifting height: 40.44m
Lifting speed:
Main hoist: 0-145m/min
Aux. Hoist: 0-145m/min
Slewing speed: 0-1.5r/min
Elevating up/ down: ≤78/ ≤70s
Boom telescoping, extending/ retracting: ≤90/ ≤70s
Outrigger telescoping:
horizontal, retracting/ extending: ≤30/33s
vertical, retracting/ extending: ≤30/33s
Chassis type: QZC5340J
Drive: 6*4
Max. traveling speed: 80km/h
Gradeability: 25%
Min. turning radius: 11m
Approach angle: 17.5 degree
Angle of departure: 12 degree
Longitudinal * transverse: 5.03*5.85m
Axles base: 4225*1350kg
Wheel span: 1st 2.088m; 2 nd&3 rd 1.800m
Tyre size: 12:00-20-18PR
Self-weight in traveling condition: 29000kg
Overall dimensions: 12.75*2.5*3.504m
|
