POWER SUPPLY:
Power source: Electric
Horsepower: 4.0
Drive motor: US ADC 48V3000W(4HP),Down hill speed reduce and Regenerative(from USA)
Batteries: US.Lead-Acid 48V; Lead-Acid / 8V150AH * 6--From USA TROJAN Battery
Charger: 48V25A
Out put torque: 10.8N/m
Speed controller:US.Curtis--from USA CURTIS COMPANY
Accelerator: US.Curtis--from USA CURTIS COMPANY
STEERING/SUSPENSION:
steering: High efficiency transmission designed
for maximum performance.(new design with steel housing provision).
Suspension: Front/Rear: Multi-piece armor plate spring, hydraulic shocks
Brakes: Mechanical drum brakes on rear wheels
Park Brake: Brake pedal
FRAME/CHASSIS:
Frame chassis: Ladder-style steel box beam
Front body:Thermoplastic,Color impregnated,pre-mix mould injection, Scratch-proof
Rear body:Thermoplastic,Color impregnated,pre-mix mould injection, Scratch-proof
Full dimensions: 2320*1210*1820mm
Packing demensions:2320*1300*1100mm
Container Loading: 8pcs/20'GP; 16pcs/40'GP,24units/40HQ
Tires Front/Rear: F/R Tire width:18*8.5-8.4Ply
Wheelbase:1620mm
Ground clearance under differential:100mm
Tread:F/840mm R/985mm
PERFORMANCE REFERENCE:
Dry weight less batteries:430kg/946 lbs
Gross weight: 500kg/1100 lbs(include battery,170kg/347 lbs)
Max.load capacity: 300kg/660 lbs
Max.forward speed: 24 km/h
Max.backward speed: 12 km/h
Braking distance:≦4m
Mileage: 80km/per charge varies from individuals and driving conditions
Climbing slope: 20 degree harsh slope with 250kg loading,full battery power;half battery power still climbing in slow speed
Seating capacity: 2 passengers include driver
Turning radius: 3.7m
|
