Displacement : 110cc
Cooling : Air cooled
Max horsepowe : 6.9hp/7500r/min
Max torque : 7.0N.M/5000r/min
Bore*stroke : 2.0*1.9inches
Max speed : 31.07mile/h
Climbing ability : 30degree
Ignition : C.D.I
Starting system : Electric
Battery : 12V/7Ah
Carburetor brand : PZ19
Engine oil : SAE15W/40SF
Gear oil : *
CHASSIS ETC :
Clutch : Semi-antomatic
Transmission : 3-speed+reverse
Driveline : Chain -drive
Driving wheel : Rear wheel drive
Suspension,front/rear : Double a-arm/single a-arm
Brakes,front/rear : Drum/disc
Brake operation : Hand
Tires,front/rear : 19*7-8/18*9.5-8
Fuel capacity/type : 1.05gal
Weight,G.W./N.W : 352.7/282.2lbs
Max load : 330.7lbs
DIMENSIONS :
Wheelbase : 43.7inches
OA L*W*H : 68.9*44.5*43.3inches
Height to seat : 26.8inches
Min ground clearance : 4.9inches
Carton size : 1465 x 860 x 780mm
Shipping info : 30pcs/20'GP 66pcs/40'GP 66pcs/40HQ
|
