Features:
1) Low cost, high reliability
2) 105oC output capacitor
3) International AC input range
4) High efficiency, low working temperature
5) Soft-start circuit, limiting AC surge current
6) Short circuit, overload, over voltage protectioln
7) Compact size, light weight
8) 100% full load burn-in test
9) Built-in EMI filter, low ripple noise
10) Weight: 550g
Specifications:
1) Input voltage: 85 - 264V AC; 120 - 370V DC (selected by SW)
2) Input frequency: 47 - 63Hz
3) Inrush current: cold start, 25A / 115V, 30A / 230V
4) Overload protection: 105 - 150% output pulsing mode
5) Over voltage protection: 115 - 135% of output voltage
6) Setup, rise, hold up time:
a) 115V AC: 800ms, 50ms, 10ms
b) 230V AC: 300ms, 50ms, 80ms
7) Withstand voltage:
a) I/P-O/P: 3kV (1min)
b) I/P-FG: 1.5kV (1min)
8) Working temp: 0 - 50oC @ 100%, -10oC @ 80%,
60oC @ 60%
9) Safety standard: UL1012, TUV EN60950
10) EMC standard: EN55022 class B, IEC801-2, 3,4,5, EN60555-2, 3
11) Connection: 5P / 9.5mm pitch terminal block
Outer packing:
30pcs/ctn
Carton volume: 1.0 cuft
G.W.: 17.0kg
|
