(1) Product dimensions: 2,690 x 1,280 x 1,960mm
(2) Minimum turing radius:4650mm
(3) Transmission:CVTand P/R/N/L/H
(4) Brake Type:F:Dual disc brake R:Single disc brake
(5) Minimum ground clearance:195mm
Engine specifications:
(6) Type:Liquid-cooled four-stroke,SOHC
(7) Bore x stroke:87.5 x 82mm(3.44x3.23in)
(8) Displacement: 493cm3
(9) Compression ration: 10.2:1
(10) Starting mode: Electric and recoil starter
(11) cylinder arragement:Forward-inclined single cylinder
(12) Oil Capaxity:2.2L
(13) Carburetion:MIKUNI BSR36-89
Capacities:
(14) Fuel tank: 19.0L
(15) Battery: 12V
(16) Maximum speed: 70kph
(17) Maximum loading capacity: 500kg
(18) Net weight: 600kg
|
