JM184

Place of Origin: China|
Model No: JM184

JM184

Detailed Product Description

ITEM JM180(2WD) JM184(4WD)
OVERALL DIMENSIONS(L*W*H)(mm) 2550*1235*1288 2675*1225*1320
WHEEL BASE(mm) 1465 1510
WHEEL TREAD(mm) FRONT 950/970-1270 950
REAR 900-1020 920-1380
GROUND CLEARANCE(mm) 330 275
TYRES FRONT 4.00-16 6.00-12
REAR 8.3-24 8.3-24
MIN.USE WEIGHT(kg) 1050 1100
RATED TRACTION FORCE(N) 3500 4100
SPEED(km/h) FORWARD
1.85
3.65
6.08
8.55
16.85
28.12 normal creeper
1.56
3.07
5.12
7.18
14.18
23.62 0.29
0.57
0.95
1.34
2.64
4.41
REVERSE
1.46
6.77 normal creeper
1.23
5.70 0.23
1.06
PTO SPEED(rpm) 540rpm or 540/1000rpm
3 HITCH TYPE CATEGORY 0
CLUTCH SINGLE STAGE OR
DUAL STAGE DUAL STAGE
LIFT CAPACITY AT 610mm(BEHIND)LIFT POINT(N) 3300
ENGINE MODEL Ty290T1
TYPE 2CYLINDER VERTICAL.WATERCOOLED 4STROKE DIESEL
RATED POWER(KW(HP)) 13.24(18)
RATED SPEED(rmp) 2200
OPTIONS OPTIONS:ROLL BAR.CANOPY.HYDRAULIC STEERING.DUAL STAGE CLUTCH.YURF TYRE,CAB
