1) Engine* Model:C6121(CAT3306)

* Type:Water-cooled,4-stroke cycle,direction,turbocharged diesel engine

* Number of cylinders:6

* Bore x stroke:102 x 120mm

* Displacement:5.9L

* Rated power:115kw/2100rpm

* Maximum net torque:651N.M

* Electrical system:24V

2) Hydraulic system

* Main pumps:Two variable diplacement piston pumps

* Maximum flow:2 x 227L/min

* Pilot pump:Gear pump

* Implement circuits:31.4Mpa

* Travel circuit:25.5Mpa

* Swing circuit:31.4Mpa

* Pilot circuit:3.9Mpa

* Cylinders/No. Of cylinders

* Boom/2:135 x 1278mm

* Arm/1:150 x 1632mm

* Bucket/1:135 x 1073mm

3) Drives & Brakes

* Gradeability:35o

* Travel speed

* High:4.9km/h

* Low:2.9km/h 4) Swing system

* Swing speed:12.5r/min

5) Undercarriage* Number of shoes:47 each side

* Width of track shoes:600mm

* Number of carrier rollers:2 each side

* Number of track rollers:8 each side

* Coolant & Lubricant Capacity(refilling)

* Fuel tank:450L

* Coolant:29.7L

* Engine:18L

* Inal drive, each side:3.3L each side

* Swing drive:3.4L

* Hydraulic tank:260L5) Overall Data

* Maximum bucket digging force:140kN

* Maximum stick digging force:112kN

* Bucket capacity:1.0m3

* Operating weight:23000kg

* Ground pressure:49kPa6) Dimensions

* Arm length:3090mm

* Maximum loading height:6700mm

* Maximum cutting height:9750mm

* Maximun digging depth:6930mm

* Maximum reach:10410mm

* Minimum turnting radius:3850mm

* Maximum vertical digging depth:6174mm

* Overall length:9960mm

* Overall width:3002mm

* Overall height:2960mm
