Asphalt Concrete Paver - Multi-Function (RP 955)
Detailed Product Description
|
Basic Working Width : 3m
Max working Width : 9.5m
Max Paving Thickness : 350mm
Paving Speed : 0 ～ 18m/min
Traveling Speed : 0 ～ 2.4km/h
Theoretical Productivity : 700t/h
Hopper Capacity :14t
Gradient Ability :20%
Smoothness :2mm/3m
Slope Leveling Tolerance :±0.02%
Engine Type : BF 6M 1013E
Rated Output: 137kw
Speed : 2300rpm
Tank Capacity : 280l
Generator Power : 28ke
Weight: 22 ～ 28.6t
Overall Dimension : 6731*3000*900mm
|
