Crawler Tractor C1302

Place of Origin: China
Model No: C1302

Detailed Product Description

engine
model :LR6105ZT14 desel engine
engine rated power /speed (kw/r/min):95.5/2200
min.fuel consumption(g/kw.h) : ≤205
oil consumption(g/kw.h) : ≤1.63
torque : ≥20%
hydraulic hitch structure:three or two point hitch
overall sizes(L*W*H)(mm)(with blade):5367*2462*2786
operation mass (kg)(with blade): 7300
track gauge(mm): 1435
wheel base(mm) :1792
track shoe width(mm) :390
groud pressure (with blade)(kpa):47.7
Gears forward
I:3.71(Drawbar pull:49.3)
II:6.85(Drawbar pull:38.9)
III:7.79(Drawbar pull:33.5)
IV:8.99(Drawbar pull:28.3)
V:10.58(Drawbar pull:23.1)
VI:13.90(Drawbar pull:15.3)
Gears reverse
I:3.31
II:6.28
max.rated lifting capacity (kn):30
blade type:stable straight blade
blade dimension (W*L)(mm):850*2462
blade digging clearance (mm): ≥330
blade lifting height :≥700
