CFT-5001 Ultrasound Scanner
Applications
This machine is used for dynamic diagnosis of visceral organs (such as liver, gallbladder, kidney, spleen, pancreas, urinary bladder and heart) in abdominal part of the human body. It has found wide application in local hospitals for clinical examination and diagnosis of disease in obstetrics and gynecology as well as examination of contraceptive ring and pregnancy. The ultrasonic examination and diagnosis is of non-intrusive image type, therefore it has no contraindications and complications related to such examination.
Technical Specification: 1, Scanning Mode: Convex, Micro Convex & Linear Array2, Probe's Standard Frequency: 2.5/3.5/4.0/5.0 MHz Convex Array Probe, 6.5MHz Trans-vaginal Probe, 7.5MHz High Frequency Linear Array Probe
3, Display Mode: B, B/B, B/M, M, 4B
4, Magnification: x 0.8, x1.0, x1.2, x1.5, x1.8, x2.05, Gray Scale: 256
6, Depth Scope: 225mm
7, Local zooming: Real-time local zooming two rates
8, Body Mark: 16
9, 8γ adjustment image post processing, 8 frame correlations image pre-processing
10, USB Port: 1
11, Dual Probe Connectors
12, Voltage: 220V/110V
Configuration: Mian Unit, 3.5MHz Convex Array Probe, 14-inch SGVA BW monitor.
Options: 6.5MHz Trans-vaginal Probe, 7.5MHz High Frequency Linear Array Probe, Video-Graphic Printer, Real Time Color Image Workstation, Cine Loop
Main Functions:1. Electronic convex array probe that has high sensitivity, long service life and no noise.
2. Advanced image processing techniques including semi-digital image processing technology, multi-segment focusing, variable aperture, logarithmic compression, dynamic filtering and TGC image control that ensure rich image gradation, clear layers and fine image resolution.
3. Near field, Far field, Total gain and Dynamic range can be adjusted and displayed.
4. Soft touch key and mouse operation that is fast, convenient and flexible.
5. Progressive scanning technique that makes the image sharper and more stable.
6. Measurement and computation function for distance, perimeter, area, heart rate and pregnant weeks. Obstetric software includes obstetric table: BPD, CRL, GS, FL, HL, LV, TBD, APBD, HC, AC, EDD and Fetus weight can be calculated automatically.
7. Real-time clock, case number, various human body signs and full-screen character notation.
8. Image freeze/unfreeze. Up/down, left/right, black/white reverse
9. Image playback. 256-frame picture playback in continuous mode or single frame review mode. It can store 128-frame picture permanently.
10. Video output port for external color monitor connection and 16 image pseudo color processing. One USB port, it can connect with computer and other store device directly, achieve real-time storing images and printting.
11. 2.5MHz/3.0MHz/3.5MHz/4.0 MHz frequency conversion function.
12. Protable or trolley selectable.
