CCTV camera, security camera, IR, Dome,CCD

Model

YS-2408C

YS-2408

YS-2402C

Image sensor:

1/3-inch Sony CCD image sensor

Effective Pixels :

PAL:752 (H) *582(V)

PAL:512 (H) *582(V)

NTSC:752(H)*492(V)

NTSC:512 (H) * 492((V)

Signal model:

NTSC/PAL

H-Resolution:

480 TV

420TV

Min.Illumination:

0.01lux

1lux

1lux

Lense installation method:

 C/CS

Back Light Compensation:

 open/close (ptional)

Autor Gain Control:

 open/close (optional)

Shutter Speed:

 1/50(1/60)~1/100,000sec

White Balance:

 open/close (optional)

S/N Ratio:

 More than 52dB

Sync-system

 Internal

Video Output:

 1.0v p-p /75 OHM

Power:

 DC12V, <120mA/AC220V,<50mA

Dimension(mm):

 119(L)*59(W)*54(H)

Weight￡¨gram￡?:
