Technical Data
Image System
- Compression: Motion JPEG hardware compression
- 350,000 pixels CMOS sensor
- f: 6.0mm to infinity, C/CS mount lens
- Min. 2.0 to 3.0 Lux (Indoor version)
- Min. 0 Lux with IR Leds (Waterproof IR version)
- Automatic Exposure Control
- Automatic Gain Control
- Automatic Brightness Control
- Automatic White Balance
- Flicker Avoidance (Flicker less)
- Resolution:
QVGA (320 x 240)
VGA (640 x 480)
- Image Frame Rate:
Max. 25 fps at QVGA resolution, average 4 Mbps/sec
Max. 15 fps at VGA resolution, average 4 Mbps/sec
- I/O Interface
CAT5, RJ-45 x1 (802.3)
RS-485 for PTZ control (OEM indoor version)
IEEE 802.11g/b Wi-Fi with WEP
Alarm in, Alarm out
Network Protocols
- TCP/IP, HTTP, ARP, ICMP, PPPoE, DHCP, SMTP, DDNS, FTP
Client
- IE6
Mechanical & Environment
- Dimensions (mm, L x H x W):
100 x 46x46 (indoor & Wi-Fi version)
155 x 78 x 75 (Waterproof IR version)
- Weight (g): 350 / 700 (Indoor/ IR)
- Power Requirement: 5 V / 1A (Indoor version) / 5 V / 2A (Outdoor version)
- Operation Temp: 5 C to 50 C (40 F to 122 F)
- Humidity: Rh10 % to 90 %
