Laser Metal Cutting Machine

Applications

Widely used in the machine manufacturing industry such as: machine tools, transport machinery, metallurgical machinery, electronics, electrical appliances, electrical manufacturing, automobile manufacturing, telecommunications, broadcasting and information industry, the aerospace industry, petroleum, chemical industry, stone, plastic , paper and rubber products industry, and so on.

Main technical parameters
     Laser wavelength: 1064nm
     Laser material: Nd: YAG
     Laser Power Rating: 300W
     Pulse Frequency: 1-150Hz work Current: 100-450A
     Pulse Width: 0.1-3ms beam divergence angle: ≤ 3 mrad
     Power instability: ≤ ± 5%
     Cutting speed: 500mm / min (1 mm thick stainless steel plate)
     Processing: X × Y = 200 × 200mm
     Repeat positioning accuracy: ± 0.2mm
     Cutting thickness ≤ 3 mm stainless steel plate ≤ 5.0 mm copper ≤ 1 mm 2 mm aluminum ≤
     Maximum input power: 16KW
     Continuous Time: 24h
     Minimum kerf width ≤ 0.2 mm (1 mm thick materials)
     Focus Lens focal lengths: 100mm
