Sell Mifare RFID Development Board

JMY-106 make use of MCS-51 as controller to complete driving RC 530, the communication interface is the SPI, which is supported by chips that above the RC530 edition. This interface has greatly reduced the link-line compared with the parallel interface, thus makes it easier to set the circuit board lines, and at the same time improve the performance of the electromagnetism compatibility for the circuit board. JMY-106 Supports card types are: Mifare One and Mifare Pro.

(1) Use MCS-51 MCU to as controller to accomplish driving RC530

(2) Can Read/write Mifare One and dual-interface Mifare Pro

(3) Occupying few (RAM) resources, only 19 byte, cost-saving

(4) Make use of RS232 to link host PC, then read/write card through the DEMO run on the host PC

(5) Dimensions (7cm*5cm*1cm), thickness (less than 1cm), and can be applied as Mifare one read and write device.

(6) Main board and antenna integrated all-in-one (The antenna can be used alone)

(7) Offered two sets of source code: C51 and A51 with same function
