Features:
baja style roll cage
hpi dirt buster tires for guaranteed high traction on all surfaces
4mm aluminum chassis
massive 23cc gasoline engine
35 minute run time
pull start
ready to run
FM radio included
chassis: baja buggy
over all length 817mm(32.2 inch)
Height: 255mm 1G (280mm with 0G)
width: front 460mm (18.1 inch) /rear 480mm
tyre track: front 395mm / rear 400mm
wheelbase: 570mm
right height: 76mm
suspension travel : front 95mm / rear 100mm
weight: 9.6kg(21.3lb)
camber: adjustable front with shims rear with screw
front caster: adjustable with shim 22 /25.5/29degrees (stock)
toe-in: adjustable front with tie rod rear with shims 2/3/4 degree each side (stock)
air craft aluminum 6061 T6 monocogue chassis
double wish bone suspension with adjustable roll center F/R
twin plate ventilated disk brake
drive system: HD metal gears with sealed gear box(8.382:1 gear ratio)
Diff: torque control viscous with 4 pinon gears sealed diff case with silicone oil
shock absorber: 5 adjustable dampening and fully adjustable coil over spring
wheel type: 3 pcs with high impact nylon material baja buggy
Engine:
2 cycle piston valve gasoline engine
cooling system: air cooled
displacement :23cc
maximum output: 2.4ps
max speed: 60km/h
fuel: pre-mixed fuel, 25(gasoline): 1(high grade 2 cycle engine oil)
700cc capacity fuel tank
starter recoil starter
Radio:
FM radio system with fail safe system
steering servo: Hi torque water resistant 25kg cm with speed 0.16sec/60 degree
Throttle servo: Hi torque water resistant 6kg cm with speed 0.16sec/60 degree
recovery battery: 6v rechargeable Nicad battery
N.W: 9.20kg (engine weight: 2.00kg)
G.W: 12kg
Carton size: 870x510x310mm
20ft/40ft/40'HQ: 230pcs/480pcs/540pcs
