car lift

Detailed Product Description

APPLICATION

floor surface mounted version, convenient for tyre operation and wheelbase maintenance.

FEATURES

1. no mechanical connections between the 2 platforms, which provides perfect workspace and maximum freedom of action underneath the vihicle.

2. the integrated emergency lowering device allows the lift to be lowered in the event of a power failure.

3. all pivot points are made of self-lubricating bearing for long life.

4. the hydraulic synchronization system with tandem cylinder prevents uneven lifting or lowering of the load.

5. very low drive-on height—115mm.

PARAMETER

capacity----------------------- 3000kg

lifting height-------------------115-2030mm

platform dimension----------1435mm*600mm

lifting time----------------------55-65s

power supply------------------220V/380V 50Hz

motor performance-----------2.2KW

compressed air supply-------6-8kg/cm²

weight----------------------------900kg
