Yingkou Xingbang Machine Co., Ltd

car lift

Detailed Product Description

APPLICATION
floor surface mounted version, convenient for tyre operation and wheelbase maintenance.

FEATURES
1.  no mechanical connections between the 2 platforms, which provides perfect workspace and maximum freedom of action underneath the vihicle.
2. the integrated emergency lowering device allows the lift to be lowered in the event of a power failure.
3. all pivot points are made of self-lubricating bearing for long life.
4. the hydraulic synchronization system with tandem cylinder prevents uneven lifting or lowering of the load.
5. very low drive-on height—115mm.

PARAMETER
capacity----------------------- 3000kg
lifting height-------------------115-2030mm
platform dimension----------1435mm*600mm
lifting time----------------------55-65s
power supply------------------220V/380V  50Hz
motor performance-----------2.2KW
compressed air supply-------6-8kg/cm2
weight----------------------------900kg
