| Features |
|
|
|
|
|
|
|
|
|
|
| Capable to decoding the high definition HVD movie format |
|
|
|
|
| Playback Video/music/photo stored in External HDD/Memory cards/USB-device |
|
|
| Supports subtitles for Mpeg4 : .srt, .sub |
|
|
|
|
|
|
| Copy media files from USB device or memory card to HDD directly |
|
|
|
| Media files previewing |
|
|
|
|
|
|
|
|
| Photo slide show with background music |
|
|
|
|
|
|
| Provide the card reader function, so as to support data exchange between SD/MMC/XD/MS cards and PCs. |
| Video Format |
|
|
|
|
|
|
|
|
|
| HVD movie decoding |
|
|
|
|
|
|
|
|
| realvideo(.rm .rmvb) |
|
|
|
|
|
|
|
|
| Mpeg1/2(.mpg .dat .vob ) |
|
|
|
|
|
|
|
|
| Mpeg4(.avi): Divx/Xvid |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Audio Format |
|
|
|
|
|
|
|
|
|
| MIDI, MP3, WMA, WAV, Ogg Vorbis,AAC, APE, FLAC and ALAC. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Photo Format |
|
|
|
|
|
|
|
|
|
| JPEG, BMP, PNG, GIF, TIFF |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Storage |
|
|
|
|
|
|
|
|
|
|
| HDD(500G), FAT32/NTFS in primary partition |
|
|
|
|
|
|
| CF/SD/MMC/MS/XD |
|
|
|
|
|
|
|
|
|
| dual USB Host ( High Speed)/ USB Device |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Output Interfaces |
|
|
|
|
|
|
|
|
|
| CVBS, S-Video, YPbPr (YCbCr), Stereo _L/R, scart |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Video Output |
|
|
|
|
|
|
|
|
|
| Interlaced HDTV: 1080ix25/30fps |
|
|
|
|
|
|
|
| Progressive HDTV: 720px50/60fps |
|
|
|
|
|
|
|
| Interlaced NTSC: 720x480x30fps |
|
|
|
|
|
|
|
| Interlaced PAL: 720x576x25fps |
|
|
|
|
|
|
|
| Progressive NTSC: 720x480px60fps |
|
|
|
|
|
|
|
| Progressive PAL: 720x576px50fps |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Specification |
|
|
|
|
|
|
|
|
|
| Power Adapter: AC 100-240V 50/60Hz input DC 5V 2A output |
|
|
|
|
| Operation Temperature: 5 degrees Centigrade to 40 degrees Centigrade |
|
|
|
| Video System: PAL/NTSC |
|
|
|
|
|
|
|
|
| Video Output: 1.0 plus or minus 0.2Vp-p,75Ω |
|
|
|
|
|
|
| Audio Output: 2.0 plus or minus 0.2V rms |
|
|
|
|
|
|
| Signal to Noise Ratio: is more than or equal to 80dB |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Size:121*101*20.4MM |
|
|
|
|
|
|
|
|
| Weight:120g |
|
|
|
|
|
|
|
|
|
| Lead time:20days |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
