ATV

Detailed Product Description

Engine:

Model KN110/150/250-H

Type 4-stroke single cylinder, air cooled/4-stroke, single cylinder with fprced air cooled/4-stroke single cylinder, air cooled

Ignition CDI

Drive Train Chain

Displacement 106.7ml / 149.5ml / 229.2ml

Bore x Stroke 52.4mm x 49.5mm / 57.4mm x 57.8mm / 67mm x 65mm

Compression 9.7

Max.power (Kw/r/min) [5.0/(8000+/-5%)] / 6.1/8000 / [11.5/(6500+/-5%)]

Max.torque (N.m/r/min) [6.7/(6000+/-5%)] / 8.3/7000 / [17.5/(5500r/min+/-5%)]

Starting system electric

Chassis:

Brakes / Front drum

Brakes / Rear disc

Tires / Front 19x7-8 / 21x7-10 / 21x7-10

Tires / Rear 18 x 9.5-8 / 20x10-10 / 20x10-10

Dimensions:

L x W x H(mm) 1610 x 930 x 1030 / 1670 x 980 x 1020 / 1590 x 980 x 1040

Net weight(kg) 140 / 150 / 175

Max.load(kg) 90 / 90 / 120

Max.speed(km/h) ≥60 / ≥55 / ≥70

Climbing ability ≥20° / ≥20° / ≥30°

Other:

Parking box size(LxWxH) 1550mm x 840mm x 830mm

Loading container QTY 63pcs/40'HQ
