FEATURES
Ultra low-noise ULN desing, highest posssible headreoom,ultra-tranparent audio;
Ultra-wide 60db gain range;
Lowest possible distortion 0.0007%(20HZ-20KHZ);
Intergrated 24 bit digital stereo DSP processor with 32 Preset including reverb,delay,chorus,
tube distortion,channel for esay to use along applications;
7 band stereo graphic EQ allow precise frequency correction of monitor or mian mixer;
2 fully equipped sero input channels,3 band EQ AND MID Frequency control;
Inserts on each MONO channel for flexible connection of outboard equipment high-headroon
line input;
3 Aux send per channel:1 pre/post fader for monitoring,1 post fader for external send,1 post fader for DSP processor;
Clip indication and gain level set LED plus mute switches for each channel allow fast and accurte level
setting;
Two sub buses and output direct or mix to main buses;
2 multi-functional setero aux returns;
Balanced main mix output with gold-plated XLR Connectors,headphone/control room output and stereo tape outputs;
Extremely rugged steel construction ensures long life even under most demanding conitions;
Switchable +48V phantom power for condenser microphone;
Long-wearing 60 mm logarithmic-taper faders and sealed rotary controls;
Response plus lowest possible power sonsumption for energy saving;
Rack mount brackets included;
Revolutionary coolaudio amplifier technology; enormouse power,incredible sonic performance and
super-lingt weight
SMT technics;
3-year warranty plus optional,3-year extwnded service contract.
SPECIFICATION
|
Mono Input Channels |
Balance MIC or Line Input |
|
Stereo Input Channels |
Balance or Unbalance Stereo Lline Input |
|
Frequency Response |
10Hz~30KHz +/-3db 20Hz~20KHz +/-0.5db |
|
MIC Sensitivity (22Hz-22KHz) |
-129.5db, 150 Ohm Source; -132db, Input Short Circuit |
|
Gain Adjustable Range |
+10db~+60db |
|
Line Input Range |
-40db~+10db |
|
SNR |
more than or equal to 113db |
|
THD |
less than or equal to 0.01%(+4db, 1KHz) |
|
EQ |
HF:12KHz+/-15db MF:5KHz+/-15db LF:80Hz+/-15db |
|
Max Input |
+22db |
|
Max Output |
+22db Balance, +16db Unbalance |
|
Effector |
24-bit DSP, Multi-effect Processor, 48KHz Sampling Frequency, |
|
|
32Effect Modes |
|
|
Memory, LCD Display |
| Power consumption |
<500w |
|
Phantom Power |
48VDC |
| Power amplifier outputs |
200w*2 @8OHM 380w*2 @4OHM |
| Configuration Dimension |
14*39.6*38(cm) |
| Packing Dimension |
46.5*46*25.5(cm) |
| Net Weight |
13.00Kg |
| Gross Weight |
15.00Kg |
|
Power Supply |
AC100~120V/200~240V 50/60Hz |
