Underwater Camera

Detailed Product Description

Image sensor: 1/3 Super Had B/W CCD Sony
Effective Pixels:NTSC of 512*492V), PAL of 500*582(V)
Resolution: 420TV lines
Synchronizing system:internal
Scanning system: NTSC 525 Lines PAL 625 Lines 2:1 Interlace
Video output: 1.0Vp-p/75 ohms
Audio output: auto
S/N ratio: More than 50 dB (AGC Off)
Min. Illumination: 0.05Lux w/o LED / 0Lux with LED on
White balance: auto
Gain control: auto
Gamma Characteristic: auto r equal to 0.45
Auto Iris control: video/DC switchable
Shutter Speed: NTSC : 1/60…1/100,000 sec, PAL:1/50…1/100,000 sec
Led Spectrum: 850nm 45 degree IR LED x 12 EA
IR view Distance:10m
Power source: 12VDC / 1 Amp
Operating current: 240mA w / regulated 12V DC
Standard Lens:6.0mm
Optional lens: 16.0mm, 12.0mm, 8.0mm, 3.6mm
Operating Temperature: -10 degree C….+50 degree C
Humidity: within 90 percent RH
Output terminal: DIY cable with BNC-Female for Video, DC Jack-Male for Power 30M Cable Measurement (mm): 70(D)*70(L)
Weight(Approx. g):1000g
