Sell DAX70 Dirt Bike (SJ70PY-1)

Detailed Product Description

Model: SJ70PY-1

Main Feature: 70cc, 4 stroke, kick start, front & rear drum brake, al-alloy wheel, chain drive, manual clutch, with speedometer and round lights,rear arm rest.

Specifications:
Engine type: Single cylinder, air cooling, 4 stroke
Clutch method: Manual
Ignition method: C.D.I.
Start method: Kick start
Transmission: Chain
Displacement(ml): 72
Bore*stroke(mm): 47*41.4
Compression ratio: 8.8: 1
Rated power(kw/r/min): 3.4/7500±500
Maximum torque(N. M/r/min): 4.5/6000±500
Lubrication: Splash
Gear: 4
Dimensions(L*W*H)(mm): 1440*380*750
Wheel base(mm): 1060
Seat height(mm): 740
Min. Turning radius(mm): 1500
Min. Ground clearance(mm): 100
Brake: Front & rear drum
Front wheel: 3.50-10
Rear wheel: 3.50-10
Fuel tank capacity(L): 2.5
Engine oil capacity(ml): 800
Climbing capacity: 15
Max. Load(kg): 75
Max. Speed(kw/h): 50
Net weight(kg): 70
Gross weight(kg): 80
