BALLAST TERMINAL BLOCK

Detailed Product Description

Product Specification：

Current: 12A;

Voltage:450V(VDE/FI/CQC);300V(UL);

Wire Range:push-in side--0.5-1.5m㎡Solid;

20-16 Solid AWG

Screw Side---2.5m㎡Rigid/Flexible

18-14 solid AWG

Strip Length:8-9 mm/ 0.32-0.36 in;

temperature:-40℃ to 110℃(VDE/FI/CQC) 105℃(UL);

Pin Spacing: 10mm;

Housing: Polyamide 66,lvory,UL 94V2;

Insert:Steel,zinc plated;

Screw:M3×7,zinc plated;
