Scope of application:
this composite stabilizer DL series are mainly used in granulation of various cables.
Functions & properties:
Excellent dispersion, reducing color difference of granules, good processing fluidity, and melting liquid can be well mixed, stable during processing. Improve the surface quality and electrical capability for the products, fast producing capability.
Technical specification:
|
Model |
Visual Appearance |
Metal Oxidate Content % |
Heating Loss% |
Melting TemperatureoC |
Density g/ml 25oC |
Dosage for reference |
|
DL-1 |
White or light yellow flake solid |
≥60 |
≤0.5 |
95-115 |
2.5-2.6 |
5.0-6.0 |
|
DL-2 |
White or light yellow flake solid |
≥45 |
≤0.5 |
85-95 |
2.2-2.5 |
6.0-7.0 |
Referenced prescription:
|
Name |
Application Quantity |
|
H-70 |
J-70 |
|
PVC |
100 |
100 |
|
CaCO3 |
20-25 |
20 |
|
Bifphenol |
0.2-0.5 |
0.5 |
|
DL-1 |
|
5-6 |
|
DL-2 |
6.0-7.0 |
/ |
|
Hst |
0.6-0.8 |
0.55 |
|
Paraffin chloride |
10 |
8-10 |
|
DOP |
30-40 |
20 |
|
PE-Wax |
0.1-0.3 |
0.1-0.3 |
|
DIDP or DOTM |
/ |
1.0-2.0 |
|
Forging argil |
/ |
4.0-6.0 |
|
Pigments |
Properly |
Properly |
Note: if J-70oC insulated material is fire retardant, add 5 pieces of Sb2O3, and proper lubricant.
Referenced usage:
Put this product, resin and other additive into high speed compounding machine till the temperature reach 90-105oC,Cool the liquid, make granule and extrude with single screw extruder.
Package:
Kraft paper sack lined with braided bags. 25±0.2 Kg/sack net
Storage:
Store in dry place, prevent form sulfide.
