Detailed Product Description
ITEM:RG-W20
Name:LED SPOT
*Source
Intensive brightness LEDs
18W RGB LEDs
60-100 thousand hrs Rated Life
*Beam angle
17 beam angle
*Dimmer,Strobe
Electronic dimmer for light output adjustment
from 0 to 100% (No colour variation)
High speed white or full colour strobe,flash
rate 1-13fps
*Mechanical Specification
Height:416mm (16.4")
Width:191mm (7.52")
Depth:126mm (4.96")
Weight:3Kg (6.6 lbs)
*Thermal
Maximum ambient temperature:40
Maximum housing temperature:60
*Control
Protocol: USITT DMX-512
Control channels: 5CH
Control options: DMX,Auto-trigger
Operation modes: Master/Slave,Stand alone,Sound
LED Control panel:Fixture addressing & parameter settings
Manual control of all DMX channels: via LED control panel
Data in/out: Locking 3-pin XLR
*Power supply
Input voltage: 90-250V AC,47-63Hz
Fuse: T 1A
Max. Power Consumption: 20VA
*COLORS
16,7million colours (24 bit)
The LEDs used are a mixture of red,green,
and blue to produce,via RGB electronic mixing.
White balance pre-programmed via LED control panel
