MICROPHONE U1000

Detailed Product Description

Main Frame Size	EIA standard 1/2-rack unit
Channels	Single-channel
Main Frame Construction	Metal frame, metal panel
Receiver Module	Fixed
Display Status	LCD/Color LCD panel displays RF/AF and diversity metering, transmitter battery fuel gauge as, Channel, Frequency, Squelch level, Mute On/Off.
Oscillation Mode	PLL synthesized
Stability	+/-0.005% (-10~50^OC)
Carrier Frequency Range	UHF 740~765MHz,UHF 765~790MHz
Bandwidth	25MHz (100 channel)
Receiving Mode	True-diversity receiving
Sensitivity	6dBuV, at S/N>80dB, 40KHz deviation
Max. Deviation Range	+/-68KHz, with level limiting
S/N Ratio	>105dB(A)
T.H.D.	<0.5% @1KHz
Frequency Response	100Hz~18KHz+/-3dB
Maximum Output Level	(6.3mm) jack socket:+4dB(1.25V)/5kOHM, XLR socket(balanced):+10dB(2.5V)/600OHM
Squelch	Innovative "PiloTone & RF Level" dual-squelch circuit.
DC Power Supply	0.5A, 12~15V DC
Dimensions	215(W)X44(H)X180(D)mm
Weight	1.25kg
Matching Transmitters	HT1000,HT400,BT200
Note	Specifications on carrier frequency range and maximum deviation vary to comply with regulations of different countries.
