MH-3Y Automatic Baby Diaper Machine
Functions and Features
It is the unique machine for producing adult diaper. Besides, according to customer’s demand, it can also produce paper mattress by adding some simple units. It runs the procedures of cotton pulp treating,
cotton core forming, pressing, embossing, waist tape and mid tape adding, cutting, folding, conveying, end seal, tri-folding and finished product output.
The application of automatic fetches and fits of phase enables the on-line readjustment of key parts without stopping the machine. Application of the vacuum conveying system guarantees the stress, stability and fixity of the product. Rational structure of the whole machine with high automation and easy operation.
1. The teech-like crusher is able to take treated or untreated pulp
2. SAP may be applied at a fixed amount in designed location or in a mixing way
3. It can produce production with two dimention by changing the die cutter and simple units
4. leakage barrier unit, unit of application of front tape, side sticker, elastic waistline and rubber band
5. the jumbo roll uncoils with stable tention, automatic paper feeding. Automatic web guide units
6. the transducer regulates the changing speed of electric motor, PLC system can be added
7. after moulding, products are folded into square type, arranged vertically and output in line
8. the dirving system consists of gear box, universal couplings and arc-gear synchronous belt.
9. web wheel in large diameter lay out the pulp to keep even thickness of cotton core under high speed operation
10. universal couplings are adopted to ensure swift transmission. The service life of the die cutter is guaranteed
11. with material unwinding and feeding system to ensure the stable tension, the speed could be accelerated in a very short time
12. the bearings, electric components are famous brand in China
13. the support, working plates and transmission plate are combined as the frame, stable operation at high speed without shaking off materials
14. double route forming
15. the glue applicator in the front of the machine, easy to control the temperature and add glue
advanced designing, low eletricity consuption and low noise, high efficiency
Technical Parameter
Power supply: 380V 50HZ
Installation capacity: 90KW
Designed production speed: 350 pcs/min
Stable production speed: 250-280 pcs/min
Product dimension:
a). XL (510-520) * 330mm,
b). L(470-480) * 320mm,
c). M(430-440) * 320mm,
d). S(380-390) * 280mm (customized)
Waster Percent: ≤2%(excluding caused by hot melt applicators failure)
Machine dimension: 20 * 1.5 * 2.8 m (L×W×H)
Weight: 25T
