Detailed Product Description
Structure and Character
1. Automatic folding, wetting, cutting, packing, seal and counting system.
2. Automatic liquid callback system.
3. Automatic production dates printing.
4. Color code automatic tracking system.
5. PLC control system, touching screen.
6. It has the feature of rational structure, easy operation and simple maintenance.
Technical Parameter
Power supply: 380V 50HZ
Installation capacity: 5.0 KW
Designed production speed: 150pcs/min
Stable production speed: 100-120pcs/min
Jumbo roll dimension: ? 1200mm * (150-200) (Dia. * Width)
Unfold dimension: (135-220 )* (150-200)mm (L*W)
Folding dimension: (67.5-110) * (55-70)mm (L*W)
Packing bag dimension: 380* (130-160)mm (L*W)
Packing film: OPP/PE, CPP, Al/PE ETE
Suitable material: spunlace nonwoven fabric, air-laid paper
Material base weight: 25-100 g/m2
Waster Percent: ≤2%
Machine dimension: 4.5 *1.0 * 1.5m (L*W*H)
Weight: 1.7T
